SQUARE D BGA24020Y1
$315.00
- BGA24020Y1 Circuit Breaker
- Brand: Square D
- Series: PowerPact
- Type: BG I-Line
- Poles: 2
- Amperage: 20
- AIC Rating: 35kA @ 480Y/277Vac, 65kA @ 240Vac, 20kA @ 250Vdc
- Molded Case Circuit Breaker
Low Price Guarantee. Re-Certified with Warranty.
1 in stock
SQUARE D FAQ:
What is suffix Y for BDA and BGA Breakers?
- Applies to I-line, 2p and 3p, Powerpact B breakers, with prefix BDA24, BDA34, BGA24 and BGA34
- The suffix Y applies to 2p and 3p I-line Powerpact B breakers that are rated to be used on a system with a maximum nominal voltage of 480Y/277 Vac.
In others words Y stands for WYE and should not be used for 480 V Delta applications.
